Alpha-Projector
Dynamic 3D Laser Projection Positioning System
AlphaProjector High-Performance Projector
AlphaProjector, a high-performance projector that combines advanced optical technology with intelligent software, designed for premium-quality projection needs.
AlphaProjector, a high-performance projector that combines advanced optical technology with intelligent software, designed for premium-quality projection needs.
Supports multiple data formats
● Supports direct import of CAD formats such as STP, IGES, DXF, and DWG Compatible with FiberSIM,
Foreign Object Detection Function
● Automatically analyzes and locates foreign objects, alerting the operator to remove them.
Automatically generate reports
● Fully document the work process to create digital records that are traceable, manageable, and statistically analyzable.
Offer a mobile app
● Control your projection hardware anytime, anywhere—no need to return to your PC.
Automatic coordinate system alignment
● Real-time automatic alignment of the coordinate system with dynamic tracking
High-quality service
● Free upgrades during the warranty period, plus dedicated training sessions.
User Management
● Role and permission settings, with complete records of operator usage information
Support for Customized Features
● Supports customized software development and provides an SDK, allowing users to independently develop the features they need.
Technical Specifications
| Technical specifications | ALPHA-T I | ALPHA-T II | ALPHA-T MAX | ALPHA-T PLUS |
|---|---|---|---|---|
| Dimensions | Length × Width × Height: 580 × 185 × 170 mm | Length × Width × Height: 580 × 185 × 170 mm | Length × Width × Height: 580 × 185 × 170 mm | Length × Width × Height: 580 × 185 × 170 mm |
| Weight | 9.5kg | 9.5kg | 9.5kg | 9.5kg |
| Sensor | Binocular Vision System | Binocular Vision System | High-Precision Binocular Vision System | High-Precision Binocular Vision System |
| Working distance | 1.3-3.5m | 1.5–8 m (customizable) | 1.5-5.5m | 1.5–8 m (customizable) |
| Projection accuracy | Maximum 0.38 mm | Maximum 0.5 mm | Maximum 0.25 mm | Maximum 0.25 mm |
| Maximum projection angle | 45° × 45° | 60° × 60° | 60° × 60° | 60° × 60° |
| Beam focusing | None | Manual focus | None | Automatic focusing |
| Environmental conditions | -5 to 40°C, 10–90% relative humidity, no condensation | -5 to 40°C, 10–90% relative humidity, no condensation | -5 to 40°C, 10–90% relative humidity, no condensation | -5 to 40°C, 10–90% relative humidity, no condensation |
| Laser class | 3R, < 5mW (not safe for direct eye viewing; customizable) | 3R, < 5mW (not safe for direct eye viewing; customizable) | 3R, < 5mW (not safe for direct eye viewing; customizable) | 3R, < 5mW (not safe for direct eye viewing; customizable) |
| Laser wavelength | 520nm | 520nm | 520nm | 520nm |
| Interface | USB 3.0 or Ethernet port | USB 3.0 or Ethernet port | USB 3.0 or Ethernet port | USB 3.0 or Ethernet port |
| Voltage | 220V | 220V | 220V | 220V |
| IP Protection Rating | IP54 | IP54 | IP54 | IP54 |
| Supported Data Types | IGES, STP, DXF, DWG—compatible with FiberSIM and CATIA CPD software formats (format customization supported). | IGES, STP, DXF, DWG—compatible with FiberSIM and CATIA CPD software formats (format customization supported). | IGES, STP, DXF, DWG—compatible with FiberSIM and CATIA CPD software formats (format customization supported). | IGES, STP, DXF, DWG—compatible with FiberSIM and CATIA CPD software formats (format customization supported). |
Relevant Materials
For a live product demonstration, scanning experience, and consultation with a quote, please contact customer service.
AlphaScan Product Manual
Product Applications
3D scanners empower industrial inspection, enabling high-precision dimension and defect analysis while boosting quality control efficiency.
3D scanners enable reverse engineering, allowing for the rapid creation of physical models and providing precise data support for product innovation.
